The Design and Evolution of Disney's Hyperion Renderer
Brent Burley, David Adler, Matt Jen-Yuan Chiang, Hank Driskill, Ralf Habel, Patrick Kelly, Peter Kutz, Yining Karl Li, and Daniel Teece

ACM Transactions on Graphics
Volume 37 Issue 3, Aug 2018. Article No. 33

Production frames from Big Hero 6 (upper left), Zootopia (upper right), Moana (bottom left), and Olaf’s Frozen Adventure (bottom right), all rendered using Disney’s Hyperion Renderer.
Abstract

Walt Disney Animation Studios has transitioned to path-traced global illumination as part of a progression of brute-force physically based rendering in the name of artist efficiency. To achieve this without compromising our geometric or shading complexity, we built our Hyperion renderer based on a novel architecture that extracts traversal and shading coherence from large, sorted ray batches. In this article, we describe our architecture and discuss our design decisions. We also explain how we are able to provide artistic control in a physically based renderer, and we demonstrate through case studies how we have benefited from having a proprietary renderer that can evolve with production needs.
